Chemical formula: C CAS accession No. 7782-42-5 Melting point 1300 ℃ to 3500 ℃ Boiling point 4830 ℃ Density 1.5g/cm --- 2.5g/cm Graphite is a gray black opaque solid with stable chemical properties and corrosion resistance. Whatsapp+8618695245206

Product Details

Chemical formula: C    CAS accession No. 7782-42-5   Melting point 1300 ℃ to 3500 ℃    Boiling point 4830 ℃    Density 1.5g/cm ³--- 2.5g/cm ³
Graphite is a gray-black, opaque solid with stable chemical properties and corrosion resistance. It is not easy to react with acid, alkali, and other agents. Graphite has the following special properties due to its special structure:
1) High-temperature resistant type: the melting point of graphite is 3850 ± 50 ℃ and the boiling point is 4250 ℃. Even if it is burned by ultra-high temperature arc, the weight loss is very small and the coefficient of thermal expansion is very small. The strength of graphite increases with the increase of temperature. At 2000 ℃, the strength of graphite is doubled.
2) Conductivity and thermal conductivity: the conductivity of graphite is 100 times higher than that of general non-metallic minerals. Thermal conductivity exceeds that of steel, iron, lead, and other metal materials. The thermal conductivity decreases with the increase of temperature. Even at extremely high temperatures, graphite becomes an insulator.
3) Lubricity: the lubrication performance of graphite depends on the size of the graphite scale. The larger the scale, the smaller the friction coefficient, and the better the lubrication performance.
4) Chemical stability: graphite has good chemical stability at room temperature and can resist acid, alkali, and organic solvent corrosion.
5) Plasticity: graphite has good toughness and can be connected into very thin sheets.
6) Thermal shock resistance: when graphite is used at room temperature, it can withstand the drastic change of temperature without damage. When the temperature changes suddenly, the volume of graphite changes little and cracks will not occur.
Micro powder graphite    Lubricating oil graphite powder   Cast graphite
Type: FS. F specification: particle size 1-38 μ m
Performance: it has oxidation resistance, self-lubrication, and plasticity at high temperatures, and has good conductivity, electrothermal, and adhesion at high temperature.

Meshes Size
Fixed Carbon
Expansion rate
32 99 1 1 300
32 99 1 1 280
32 85 15 1 150
50 99 1 1 250
50 95 5 1 250
50 85 15 1 250
50 85 15 1 180
80 99 1 1 200
80 95 5 1 200
80 85 15 1 150
120 85 15 1 120
100 85 15 1 100


1. Used as demoulding lubricant in catalyst production of the chemical fertilizer industry.
2. Lubricant base material corrosion-resistant lubricant base material.
3. Powder metallurgy release agent and metal alloy raw materials.
4. Make fillers or performance improvers for rubber plastics and various composite materials to improve the wear resistance compression resistance or conductivity of materials.
Graphite has good chemical stability. Processed graphite has the characteristics of corrosion resistance good thermal conductivity and low permeability. It is widely used to make heat exchangers reaction tanks condensers combustion towers absorption towers coolers heaters filters and pump equipment. It is widely used in the petrochemical industry hydrometallurgy acid-base production synthetic fiber papermaking and other industrial departments which can save a lot of metal materials.
Refractory materials and coatings for metallurgical industry. Such as magnesia carbon brick and crucible graphite is often used as the protective agent of ingot and the lining of metallurgical furnace in steelmaking. Heat dissipation material heat insulation material
Anticorrosive coating As an anti-corrosion material it is an antirust primer made of carbon black talc powder and oil which has good corrosion resistance to chemicals and solvents; If zinc yellow and other chemical pigments are added to the formula the antirust effect is better.
Wear-resistant lubricating material Graphite is often used as a lubricant in the machinery industry. The lubricating oil can not be used at high-speed high temperatures and high pressure while graphite wear-resistant material can work without lubricating oil at a high sliding speed at 200 ~ 2000 ℃. Many types of equipment conveying corrosive media are widely made of graphite materials such as piston cup sealing ring and bearing. They do not need to add lubricating oil during operation. Graphite emulsion is also a good lubricant for many metal processing (wire drawing and pipe drawing).
Casting sand turning to die pressing and high-temperature metallurgical materials Graphite has a small coefficient of thermal expansion and can withstand the changes of rapid cooling and heating. It can be used as the mold of glassware. After using graphite the ferrous metal can obtain the casting with accurate size smooth surface and high yield. It can be used without processing or slight processing thus saving a lot of metal. In the production of cemented carbide and other powder metallurgy processes graphite materials are usually used to make ceramic boats for die pressing and sintering. The crystal growth crucible of monocrystalline silicon regional refining container support fixture and induction heater are all processed with high-purity graphite. In addition graphite can also be used as graphite insulation board and base for vacuum smelting high-temperature resistance furnace tube rod plate grid and other components.
